Ubiquiti UniFi Pro Max 48 PoE Network Switch - USW-Pro-Max-48-POE
$2,023.00
Ubiquiti UniFi USW-Pro-Max-48-PoE Pro Max 48 PoE Network Switch
The Ubiquiti UniFi USW-Pro-Max-48-PoE is a powerful 48-port Layer 3 Etherlighting switch designed for high-power PoE++ output. It is ideal for networks that require extensive power delivery, high-speed connectivity, and enhanced visual management.
Key Features
- 48-port Layer 3 network switch
- 16 x 1/2.5 GbE RJ45 ports
- 8 x PoE+ ports
- 8 x PoE++ ports
- 32 x GbE RJ45 ports
- 24 x PoE+ ports
- 8 x PoE++ ports
- 4 x 10G SFP+ ports for high-speed uplinks
- Etherlighting ports that illuminate for:
- Port location
- Speed/link status
- Native VLAN/network
- DC power backup ready (USP RPS DC input)
- 720W total PoE availability
- Total non-blocking throughput: 112 Gbps
- Switching capacity: 224 Gbps
Enhanced Etherlighting Visibility
The USW-Pro-Max-48-PoE includes Etherlighting ports that illuminate to indicate port location, speed/link, and native VLAN/network. When used with UniFi Etherlighting Patch Cables, this feature enhances visibility and makes network identification and management easier and more intuitive.
High-Power PoE++ and Flexible Connectivity
With a blend of 2.5 GbE and GbE ports, plus PoE+, PoE++, and 10G SFP+ uplinks, the USW-Pro-Max-48-PoE offers flexible options for powering and connecting a wide range of devices while supporting data-intensive operations.
Specifications
Mechanical
| Parameter | Detail |
|---|---|
| Dimensions | 442.4 x 399.6 x 43.7 mm (17.4 x 15.7 x 1.7") |
| Weight (without brackets) | 6.2 kg (13.7 lb) |
| Weight (with brackets) | 6.3 kg (13.9 lb) |
| Enclosure material | SGCC steel |
Hardware
| Parameter | Detail |
|---|---|
| Management interface | Ethernet In-Band |
| Networking interfaces | (32) GbE RJ45 ports |
| (16) 1/2.5 GbE RJ45 ports | |
| (4) 10G SFP+ ports | |
| PoE interfaces | (32) PoE/PoE+ (Pins 1, 2+; 3, 6-) |
| (16) 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-) | |
| Total non-blocking throughput | 112 Gbps |
| Switching capacity | 224 Gbps |
Power
| Parameter | Detail |
|---|---|
| Power method | Universal input, 100–240V AC, 50/60 Hz |
| DC input | USP RPS DC input |
| Power supply | AC/DC, internal, 820W |
| Supported voltage range | 100–240V AC |
| Max. power consumption | 100W (excluding PoE output) |
| Total available PoE | 720W |
| Max. PoE wattage per port | PoE: 15.4W |
| PoE+: 30W | |
| PoE++: 60W | |
| Voltage range PoE mode | PoE: 44–57V |
| PoE+: 50–57V |
Controls & Display
| Parameter | Detail |
|---|---|
| LCM display | (1) 1.3" touchscreen |
| Button | Factory reset |
Environmental & Certifications
| Parameter | Detail |
|---|---|
| Operating temperature | -5 to 40° C (23 to 104° F) |
| Operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
Etherlighting Indicators
Ethernet Ports
- Locating
- Speed/link
- Native VLAN/network
SFP+ Ports
- Locating
- Speed/link
- Native VLAN/network
LEDs
- System status
- RPS status
Box Contents
- 1 x USW-Pro-Max-48-PoE Switch
- 4 x Rubber feet
- 1 x UK power cable
- 1 x Pair rackmount ears
- 1 x Rackmount accessories set
